Description

Application: Closer designed for frequent use in low-abusive traffic areas on aluminum, hollow metal, or wood swinging doors and frames

Excellent Choice For:
• Aftermarket replacements
• Aluminum storefronts
• New construction

Spring Size:
• Adjustable Spring Size 1-6
• 1450 Series: Medium Duty: Designed for frequent use in low-abusive traffic areas

Mounting: Hinge (Pull Side), Top Jamb (Push Side), Parallel Arm (Push Side)

Body Construction:
• Cast Aluminum Body
• Full Complement Bearing
• 1-1/4″ Diameter Piston
• 5/8″ Diameter Single Heat Treated Pinion Journal

Fluid: All Weather Fluid

Handing: Non-Handed

Templating: Peel-n-Stick templates – 3/4″ x 12″ Mounting Hole Pattern

Warranty: 1450 Series: 25 year limited warranty

Finishes:
• Aluminum – 689
• Dark Bronze – 695
• Black – 335
• Bright Brass – 603

Fasteners:
• 1450 series closers are shipped with: A standard universal screw pack:
• Self-reaming and tapping screws (SRT)
• Machine screws and wood screws
• Standard LCN thru bolts (TB) can be installed on 1-3/4″ (44 mm) thick doors with 1/4-20 machine screws
• Optional thru bolt (TB) sizes are available for 1-5/8″ (41 mm) or 1-3/8″ (35 mm) door thickness, must be specified when ordering

Certifications:Â Grade 1 – ANSI A156.4, UL 10C, ADA, 100 Hour Salt Spray, Meets BAA – Buy American Act

Accessories:
• 1450 Series: Medium Duty:
• 18 – Plate for Hinge Side Mount (18)
• 18PA – Plate for Parallel Arm (18PA)
• 18FC – Plate Used with Full Cover for Pull Side and Top Jam Arm (18FC)
• 18PAFC – Plate Used with Full Cover for Parallel Arm (18PAFC)
• 61 – Blade Stop for Cush Shoe Support (61)
• Slim Line Plastic Cover (72); Optional Handed Metal Cover (72MC)
• Optional SRI

• The patent-pending design of the 1450 Series makes it a top choice for a range of medium-duty applications: aftermarket replacement, aluminum store fronts and new construction. It is available with a standard slim line cover, and two available standard finishes and custom colors. It also features the industry’s most common hole pattern, and is ANSI/BHMA A156.4 Grade 1 certified. This results in a closer made of top LCN quality, engineering and service, all at a competitive price.
